Until recent years, standalone 8-bit and 32-bit microcontrollers ran monolithic C++ firmware via custom Marlin configuration files. While Marlin remains reliable for single-board budget units, modern performance pushes kinematics math beyond low-power microcontrollers. Klipper firmware reorganizes control by splitting compute tasks across two devices.

A host computer, typically a Raspberry Pi or an equivalent single-board Linux computer, handles step generation, trajectory planning, and G-code parsing. It streams scheduled motion commands over high-speed serial USB or UART to the microcontrollers on the mainboard and toolhead. This architecture unlocks real-time mathematical compensations, particularly input shaping calibration.

When an extruder accelerates rapidly, the sudden physical jerk excites the machine's mechanical resonance frequencies, creating ghosting or ripples on outer walls. By bolting an ADXL345 or LIS2DW SPI accelerometer directly to the toolhead and print bed, Klipper commands the motors through rapid vibration sweeps across 1 Hz to 120 Hz. The software measures mechanical resonances and calculates anti-resonance filter parameters:

<pre style="background-color: #f8fafc; border: 1px solid #e2e8f0; padding: 12px; border-radius: 6px; font-family: monospace; font-size: 0.9em; overflow-x: auto;">

[input_shaper]

shaperfreqx: 58.4

shapertypex: mzv

shaperfreqy: 46.2

shapertypey: ei

dampingratiox: 0.05

dampingratioy: 0.05

</pre>

By applying tailored mathematical equations like MZV (Minimum Zero Vibration) or EI (Extra Input) to motor step timings, Klipper cancels out physical resonances before they reach the belt system. This software-driven dampening allows acceleration rates above 8,000 mm/s² while maintaining clean, ripple-free outer surfaces.
