Controlling a probe flying at 17 kilometers per second with an extreme radio signal latency introduces unprecedented operational hurdles. Commands cannot be sent interactively. If flight engineers send instructions to adjust instrument heaters at 08:00 UTC on a Monday, the craft does not execute that line of code until Tuesday morning. Telemetry confirming success cannot reach ground stations until Wednesday morning.

The communication channel relies on the massive 70-meter paraboloid dishes of the NASA Deep Space Network located in Goldstone (California), Madrid (Spain), and Canberra (Australia). Because Voyager 2 flies so far to the celestial south, only the southern hemisphere station in Canberra can pick up its signals. Voyager 1, perched far to the north, is tracked by stations across the Northern Hemisphere.

Engineers face a vanishing power budget. The probe's radioisotope thermoelectric generators (RTGs), powered by decaying pellets of plutonium-238, shed about four watts of electrical capacity each year. The transmitter broadcasts with only about 8 watts of power, roughly equivalent to a refrigerator bulb. By the time that signal travels one light-day across the void, the radio waves arriving on Earth are measured in fractions of a billionth of a trillionth of a watt, requiring cryogenic receivers and algorithm-assisted signal stacking to decode a 160-bit-per-second stream.
